Allen-Bradley Touch Screen Control Spray Cooling Machine (Tunnel ) For Juice filling Line

Ask Lasest Price
Brand Name :	Longway
Model Number :	ZLP
Certification :	CE SGS
Payment Terms :	TT ,LC
Supply Ability :	100SET
Delivery Time :	35days

Add to Cart

Product Details
Company Profile

Allen-Bradley Touch Screen Control Spray Cooling Machine (Tunnel ) For Juice filling Line

Quick Details

Type:	Packaging Line, Bottle Tunnel Pasteurizer	Condition:	New	Application:	Beverage, Commodity, Machinery & Hardware, Juice.dairy,
Packaging Type:	Bottles, Cans	Packaging Material:	Plastic	Automatic Grade:	Automatic
Driven Type:	Mechanical	Voltage:	380V/or customer requirement	Power:	96KW
Place of Origin:	Jiangsu, China (Mainland)	Brand Name:	LONGWAY	Model Number:	LP
Dimension(LWH):	L10000W1800H2350mm	Weight:	10500KG	Certification:	CE ISO
After-sales Service Provided:	Engineers available to service machinery overseas	Material:	SUS304	Warranty:	2 Years
Usage:	Spray Tunnel Pasteurizer for sauce

Packaging & Delivery

Packaging Details:	Wooden case
Delivery Detail:	Shanghai

Product Description

1Tunnel Pasteurizer sterilizer,pasteurizing milk,juice pasteurizing
2This unit can used to sterilize the beer, juice and others

Tunnel Pasteurizer sterilizer,pasteurizing milk,juice pasteurizing

Based on advanced same technologies from Germany, Italy and Taiwan, we developed this new type of bottle cooling/heating machine.

Its working process can be divided into 3 stages: circulating hot water spraying, warm water pre-cooling and cold water cooling. The cooling/heating temperature and time can be regulated according to the requirements of users.

It is suitable for cooling or heating all kinds of bottled or canned hot beverage and aerated beverage.

It equips with Rexnord(American famous brand) chain plate, which is made of high temperature resistance polypropylene (CPP).

Its structure is made of fine stainless steel. So the machine is more reliable in running, also it has a beautiful appearance.

Main Technical parameters
Model	LP-3000		LP-6000	LP-10000
Capacity(b/h)	2000-3000		4000-6000	8000-10000
Bottle inlet temperature()	5-10
Bottle outlet temperature()	<45
Sterilizing temperature()	62-63/85-92
Sterilizing time(min)	10( Adjustable)
Steam pressure(MPa)	0.5-0.6
Width of chain (m)	1.22	1.5		1.5
Circling water(m3/h)	10	20		40
Water consumption(m3/h)	1	1.5		2
Steam consumption (kg/h)	200	350		600
Overall dimension (mm)	800015001850	1100018001850		1560018001850
Weight (kg)	4800	7200		9600

Product Picture

Allen-Bradley Touch Screen Control Spray Cooling Machine (Tunnel ) For Juice filling Line
